Model features
01Active 0 ms and passive below-10 ms transfer
02Up to 99.3% DC-coupled charging efficiency
03Export limitation, self-consumption and peak shaving
04Up to three systems in parallel
05Diesel hybrid grid-forming operation
06IP54 all-in-one enclosure
Key specifications
Rated power125 / 250 / 375 / 500 kVA
Battery voltage680-900 V
PV inputOne to four 120 kW inputs
Transfer timeActive 0 ms; passive below 10 ms
Ingress protectionIP54 / IP20
Dimensions1200 x 2000 x 1000 mm
WeightApproximately 490-850 kg
Product gallery
