Model features
01Grid-forming and grid-following operation
02125% overload capability for 60 seconds
03Heterogeneous battery SOC balancing
04AC- and DC-coupled architectures
05Independent three-phase grid control
06Frame-mounted installation
Key specifications
Rated power100 / 125 kVA
Battery voltage680-900 V
Maximum efficiency98.5%
Maximum charge current150 / 200 A
TransferExternal STS integration
Dimensions440 x 720 x 200 mm
WeightBelow 50 kg
